Forbes Marshall Piston Valve
| Stok | Tersedia |
| Kategori | Forbes Marshall |
Forbes Marshall Piston Valve
FM Piston Valve is a seatless and glandless valve. The heart of the FM Piston Valve is Piston and Sealing Ring. A burnished Piston seals against metal reinforced graphite rings to achieve leak proof shutoff. This unique design ensures long life even at high temperature – up to 427 °C.
Energy Audits done at various sites have reveale that valve leakage is the most serious concern in the industry. In a typical 5 year old plant, over 30% of the isolation valves actually leak.
Features :
- Larger effective sealing area – 88% more than Globe Valve; Zero Leakage assured.
- Durability – Piston unexposed to media.
- Absence of Gland & Valve Key.
- The only scrap free valve.
- Fire Proof.
- Maintenance frienly.
- Self cleaning.
- Self lubricating
Description and Application
Forged carbon steel Forbes Marshall Piston Valves provide perfect tightness and durable stability on different media such as steam, superheated steam, heat transfer fluid, ammonia, LPG, acids, alkalies etc.
Size and pipe connections
15NB, 20NB, 25NB, 32NB, 40NB
Screwed BSPT / NPT ends
Socket weld ends
IBR APPROVED VALVES AVAILABLE ON REQUEST
